Pressure Range: Class 150 ~ 2500 Nominal Size Range: DN 15 ~ 900, NPS 1/2" ~ 36" Connection: Flange (RF, FF, RTJ), Butt Welded (BW), Socket Welded (SW), Threaded (NPT), Screwed Full Port Design Out Side Screw and York (OS & Y) Bolted Bonnet (BB) Rising Stem or Non-Rising Stem Hand Wheel Renewable seat rings
Design Specifications:
Design and Manufacture: API 600, API 6D Face to face (end to end): ANSI B16.10 Flanged connection: ANSI B16.5 Butt welded end: ANSI B16.25 Test and inspection: API 598, API 6D Wall thickness: API 600
All valves are designed to comply with the requirements of ASME B16.34, and the ASME as well as customers' requirements as applicable.
Gear, Electric, Cylinder, Pneumatic, Hydraulic, Hand wheel, Chain wheels
Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
Quality Control (QC):
The QC is responsible for all aspects of quality, from receiving of material to control of machining, welding, nondestructive examination, assembly, pressure testing, cleaning, painting, and packaging.
Pressure Testing:
Each valve is pressure tested in accordance with ASME B16.34, API 598, or special customers' requirements as applicable.
