Design Features:
Pressure Range: Class 150 ~ 2500
Nominal Size Range: DN 15 ~ 900, NPS 1/2" ~ 36"
Connection: Flange (RF, FF, RTJ), Butt Welded (BW), Socket Welded (SW), Threaded (NPT), Screwed
Full Port Design
Out Side Screw and York (OS & Y)
Bolted Bonnet (BB)
Rising Stem or Non-Rising Stem Hand Wheel
Renewable seat rings
Design Specifications:
Design and Manufacture: ADIN3352
Face to face (end to end): AEN558-1
Flanged connection: EN1092-1
Butt welded end: AEN12627
Test and inspection: DIN 12266
All valves are designed to comply with the requirements of DIN as well as customers' requirements as applicable.
Body Material:
1.0619,1.7363,1.4552,1.4581
Actuators:
Gear, Electric, Cylinder, Pneumatic, Hydraulic, Hand wheel, Chain wheels
Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures.
Quality Control (QC):
The QC is responsible for all aspects of quality, from receiving of material to control of machining, welding, nondestructive examination, assembly, pressure testing, cleaning, painting, and packaging.
Pressure Testing:
DIN 12266
