Design Features:
Nominal Size Range: DN15 ~ DN350
Pressure Rating: PN16 ~ PN64
Connection: Flange (RF, FF, RTJ), Butt Welded (BW), Socket Welded (SW)
Design Specifications:
Design: API 599, API 6D
Pressure-temperature rating: ASME B16.34
Face-to-face dimensions for butt weld and flanged valves: DIN 3202 F1
Flange design: DIN2543-2549
Butt welding design: DIN3239
Body Material:
1.0619, 1.7363, 1.4552, 1.4581
All valves are designed to comply with the requirements of DIN as well as customers' requirements as applicable.
Actuators:
Gear, Electric, Cylinder, Pneumatic, Hydraulic, Lever, Chain wheels
Body Material:
1.0619,1.7363,1.4552,1.4581
Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
Quality Control (QC):
The QC is responsible for all aspects of quality, from receiving of material to control of machining, welding, nondestructive examination, assembly, pressure testing, cleaning, painting, and packaging.
Pressure Testing:
Each valve is pressure tested in accordance with DIN3230, or special customers' requirements as applicable.
